Virtual Event
Microscience Microscopy Congress 2021

MMC 2021

Meet Oxford Instruments at MMC 2021

The Microscience Microscopy Congress is a key occasion in the Microscience calendar, and to reflect this, Oxford Instruments is supporting the event with numerous activities, alongside Gold-level sponsorship!

As well as featuring in the presentation by RMS Ambassador, Rob Kessler, our team is fully involved with the MMC activities. In addition to presenting during the conference programme, we are holding workshops on a broad range of topics. We are also holding a Technical Showcase.

If you have a specific question we can help with, come and speak to us on our virtual stand.

Even if you can’t make it to MMC, you can still live chat with us or request a demo here.




5th - 9th July 2021


Andor, Asylum Research, NanoAnalysis

MMC 2021

MMC Activities

At MMC, we will be getting involved in various activities. The schedule, which includes conference presentations, workshops and a technical showcase, is details below.

If you can’t make it to MMC, you can still live chat with us or request a demo from the website.



Kim LarsenMicroscopy applied to Battery materialsTuesday 6th1245 - 1315
Jonathan Moffat & Chris MulcahyCypher VRS1250 Video-Rate AFMTuesday 6th1400 - 1430
Sam MarksGetting the most out of your EDS in the TEM: M2T quantification, EDS based sample thickness measurements and moreWednesday 7th1345 - 1415
Chris Mulcahy & Marta CohunJupiter-XR AFM:  High resolution, high stability, and high speedThursday July 8th 1600 - 1630

Technical Showcase

Anthony HydeAZtecLive chemical imaging: revolutionising sample navigation and analysisTuesday 6th1550 - 1555

Discover our Latest Products

We will be at MMC talking about some of our leading edge products which are designed to enhance the detection and measurement capabilities for your laboratory research, increase speed to result and provide superior data analysis capabilities. Come and find out about AZtecWave which unleashes the power of WDS; AZtecCrystal2 and Symmetry S2 which allow you to combine the world’s most modern EBSD data processing software with the ground-breaking performance of the world’s first CMOS-based EBSD detector; and the Asylum Research Jupiter XR and Cypher Atomic Force Microscopes, leading technologies for biomolecules and membranes, semiconductors, polymers, 2D materials, thin films, energy, and quantum..

You can learn more about these ground-breaking new products by visiting the booth.



AZtecWave lets you combine the unparalleled accuracy of Oxford Instruments AZtecLive EDS technology for element detection and composition determination with the highest spectral resolution WDS to reliably detect and accurately quantify trace or minor elements, even when X-ray lines are heavily overlapped by major element peaks in EDS.

Our unique technology unleashes the power of WDS, without the complexity. Workflows are fully integrated and designed specifically for combined EDS and WDS within the AZtec platform. EDS information is used to automate the WDS set-up to ensure the best results are achieved in the minimum time, working at optimum conditions. Whether you’re working in the fields of metallurgy, electronics, geology, or beyond, AztecWave accelerates your time to results, helping you achieve more in less time, with unparalleled accuracy and certainty.

Find out More



The latest AZtecCrystal is the world’s most modern EBSD data processing software and builds on the original product’s success.

Capable of handling the massive datasets commonplace when using the latest CMOS-based EBSD detectors, like Symmetry S2, AZtecCrystal will suit the needs of all levels of EBSD user. For the occasional user, the intuitive interface and intelligent data handling make extracting key information from EBSD datasets a simple process. For the expert, it provides all the advanced tools required to thoroughly interrogate any dataset.

AZtecCrystal now includes rapid parent grain reconstruction among its numerous high-end developments, such as the calculation of elastic properties of materials and an advanced machine-learning based classification tool, as well as functionality to further improve throughput and ease of use.

Whatever your EBSD data processing needs, AZtecCrystal delivers the answers.

Find out More

Symmetry S2


The ground-breaking performance of the world’s first CMOS-based EBSD detector is about to get better.

Offering an acquisition speed of >4500 pps with no compromise on sensitivity, Symmetry S2 delivers routine high-speed analysis on all sample types and excellent data from beam-sensitive materials.

Combining the speed of CMOS with unique fibre optics, proximity sensing, and a software-controlled tilting interface makes the S2 detector the most versatile and powerful on the market.

Symmetry S2 is driven by the power and simplicity of the AZtecHKL data acquisition software and completed by AZtecCrystal, the most modern EBSD data processing platform available, developed to cope with the large datasets generated by CMOS EBSD.

When an EBSD detector has no compromise, no application is beyond your reach.

Find out More

Jupiter XR

The Jupiter XR Atomic Force Microscope is the first and only large-sample AFM to offer both high-speed imaging and extended imaging range in a single scanner configuration. Jupiter XR can accommodate samples up to 200 millimetres in diameter and inspect areas up to 100×100 microns while still delivering ultra-high resolution and high throughput, with typical images requiring <1 minute to acquire. Standard features, such as Asylum Research’s pioneering blueDrive photothermal excitation make the experimental setup simple, imaging stable and fast.

The newly developed Ergo software interface included with Jupiter XR AFM provides streamlined workflow that enables quick setup and simple acquisition of consistent high-quality images. Jupiter XR versatility, high quality data and ease-of-use allows it to excel in both academic research and industrial R&D laboratories.

Find out more

Cypher AFM

The Asylum Research Cypher family of AFMs is comprised of three models: the Cypher S base model, the Cypher ES with environmental controls, and the Cypher VRS1250 video-rate AFM. All three models are designed from ground up to achieve ultra-high spatial resolution. Cypher AFMs easily and routinely achieve molecular and atomic scale resolution on samples including biomolecules, 2D materials, and polymers. The Cypher ES features a fully-sealed sample cell that is the foundation of environmental control options including heating, cooling, humidity control, and an electrochemical cell. The Cypher S and Cypher ES are also designed to support fast scanning. While conventional AFMs take several minutes to capture an image, fast scanning Cypher AFMs can capture images in several seconds for improved productivity. The Cypher VRS1250 takes imaging speed to a new level, capturing nanoscale dynamics at up to 45 frames/second.

Find out more

Life Science Imaging Solutions...

At Andor, it matters to us that the products we develop make a real difference to our customers and contribute significantly to their research across Immunology, Microbiology, Neuroscience, Cells & Tissues, Pharma and much more. It excites us that our ground-breaking low light imaging microscope cameras, spectroscopy solutions and microscopy systems are widely used in papers published in high-impact journals like Nature, the Journal of Cell Biology and many more.

Technology Applications

Oxford Instruments technologies are being used in an array of research, manufacturing and medical applications to help address a wide variety of issues. Applications related to our activities at MMC 2021 include the field of bioimaging and life science and battery development.

BioImaging and Life Science

Characterisation of cellular structure and dynamics is fundamental to understanding biological processes. Biological samples are delicate, and answers are often needed fast and with no fuss. At Oxford Instruments, we have a wide range of sophisticated solutions to help you achieve your goal. Whether you need rapid diagnostics using BioMEMS, are imaging and characterising structures from whole organisms to mitochondria using electron, X-ray or optical microscopy, or are working over a range of length scales and techniques to visualise cellular dynamics, Oxford Instrument can help.

This year at MMC, Oxford Instrument activities directly related to BioImaging and Life Science include:

Louise Hughes & Jonathan MoffatPresentationCorrelative EDS and AFM reveals compositional changes in tooth dentine and enamel exposed to acid solutions compared with alterations in topography and material propertiesTuesday 6th1059 - 1111

Battery Development

Advances in battery are vital if we are to achieve a carbon-neutral future for our planet. Oxford Instruments can support your battery research or manufacture across the whole value chain with a range of analytical and microscopy techniques across the whole value chain. We offer state-of-the-art solutions from our range of electron and atomic force microscopy, deposition and etch equipment and NMR as well as scientific cameras. From elucidating the fundamental electrochemical and materials challenges in battery research to providing tools for the quality control of battery anodes, cathodes and electrolytes.

Relating to Battery technology at MMC 2021, Oxford Instrument activities include:

Kim LarsenWorkshopMicroscopy applied to Battery materialsTuesday 6th1245 - 1315

Request a demo

Even though we can’t meet face to face, there are still many ways you can find out about how Oxford Instruments can help you with your nanoanalysis or imaging challenges.  This includes a remote, online demonstration of any products and solutions. If you would like to know more about how our latest generation hardware or software releases perform, please request a demo. We’d be delighted to show you how we can help you achieve your goals.

Please fill out the form below to book your demo.
